1325-2536 large format laser marking machine
Large format laser marking machine
Dual-Axis Synchronous Movement
Enables high-speed marking, engraving, seamless stitching, and fast punching with exceptional precision and efficiency.Gantry Structure
The gantry moves together with the marking head, supported by high-precision linear modules and a heavy-duty base.
Ideal for ultra-large format marking with seamless results, nearly invisible to the naked eye.High-Precision Motion Module
Uses high-precision linear guide rails with flatness ≤ 0.2 mm and repeat positioning accuracy of 0.02 mm, ensuring stable and accurate marking.Customized Industrial Laser
Supports a wide range of effects on metal materials, including whitening, blackening, deep engraving, and mirror coating removal.
Mirror peeling and sanding can be completed in one single process.
| Serial number | name | parameter |
| one | Equipment model | CZ-F100-1325A/B/C |
| two | laser power | 60w/100w/120w |
| three | Laser wavelength | 1064 ± 3nm |
| four | Beam quality | M2≤1.2 |
| five | Marking range | 6060/1325/2536 optional |
| six | Engraving depth | ≤5mm (depending on the material) |
| seven | Engraving speed | 600 characters/second |
| eight | Minimum line width | 0.01mm |
| nine | Minimum character height | 0.3mm |
| ten | Repetition accuracy | ± 0.1mm |
| eleven | Power consumption of the whole machine | ≤ 2000-5000w |
| twelve | Power demand | 220v/50-60hz |
| thirteen | Cooling mode | Air cooling |
- Contact information
Email: sales@xzlasers.com
WhatsApp: +8617702282583
1. We offer reliable international payment options:
- Letter of Credit (L/C): Ideal for high-value orders, ensuring security for both buyer and seller.
- Telegraphic Transfer (T/T): Common method — 30% deposit in advance, 70% balance before shipment.
- PayPal / Western Union: Suitable for small parts or sample payments (not recommended for full-size machines).
2. Delivery Methods
Due to the size and weight of our glass laser equipment, we primarily ship via ocean freight:
- Sea Freight (Container Shipping): The most suitable and economical solution for all equipment models.
- Air Freight: Not available for most full-size machines. Can be arranged for small accessories or demo units upon request.
3. Delivery Time
- Production Lead Time: Usually 30–50 working days after receiving the deposit.
- Shipping Time: Delivery varies by destination. Typically 15–40 days by sea, depending on the port location.
4. Shipping Costs
Shipping costs depend on the destination port, machine dimensions, and total weight.
- Contact information
Email: sales@xzlasers.com
WhatsApp: +8617702282583
1. Warranty Period:
Laser Machine: 18 months
Within 12 months, free replacement of parts, including the laser device.
For failures caused by non-human reasons, our company will send new accessories to customers for free, including the laser source.
Customers will need to send back faulty parts (laser source) first.
For other parts, there is no need to return them.
From 12 to 18 months, the customer will bear the laser cost and postage.
Both parties will share the postage cost for the return of the laser device.
The customer will send the faulty laser to our bonded warehouses in Jinan or Shenzhen, China. The purpose of this is to avoid complex customs procedures.
After 18 months, the laser source will cost, and the customer will need to buy the parts and cover the postage costs.
2. Laser Charging Instructions
| Time | Laser | Remark |
| Within 12 months | Free replacement | Both parties pay the postal fee (If received within one month, customer bears no cost) |
| 12–18 months (During the warranty period) | Laser source cost × 0.2 | Both pay postage Send to bonded warehouse in China (Jinan/Shenzhen) |
| After 18 months (Out of warranty) | Laser source cost × 1.2 | Buy directly, customer pays postage |
- Contact information
Email: sales@xzlasers.com
WhatsApp: +8617702282583
1. What materials are suitable for fiber laser marking machines?
Mainly used for metals such as stainless steel, aluminum, copper, and iron. It can also mark certain plastics and PCB boards.
2. What is the typical marking depth and precision?
Marking depth ranges from 0.01 to 0.5 mm, with precision up to 0.01 mm, depending on the power and material.
3. Does it require consumables? Is maintenance difficult?
No consumables are needed. The core components have a lifespan of up to 100,000 hours. Daily maintenance only requires cleaning the optical lens.
4. What are the advantages of fiber lasers compared to other types?
Fast speed, low power consumption, clear marking results, and excellent wear resistance—ideal for high-volume production.
5. Can it support automation or flying marking?
Yes, it can be integrated with production lines or robotic arms to perform dynamic flying marking for improved efficiency.
